1-776087-1 23-Pin Right Angle Automotive Connector PCB Header Replacement

Description

The 1-776087-1 23-Pin Right Angle Automotive PCB Connector is a compact wire-to-board solution designed for automotive electronic assemblies and vehicle electrical systems. It features a 23-position, 3-row configuration with a 4 mm centerline, providing multiple connection points within a relatively compact PCB layout. The right-angle design allows the mating harness to connect from the side, making it suitable for applications where PCB space and connector orientation need careful consideration.

The connector is designed for through-hole PCB mounting and uses a sealed housing to provide additional protection in demanding operating environments. Gold-plated contacts support stable electrical connection and help maintain consistent contact performance. Typical applications include automotive control modules, PCB assemblies, vehicle wiring systems, and electronic equipment.

Specification

Product Features

• 23-Pin, 3-Row Configuration
  Provides 23 connection positions in a three-row layout, suitable for multi-circuit automotive PCB assemblies.

• Right-Angle PCB Mounting
  The 90-degree mounting orientation allows the mating harness to approach from the side, helping improve connector routing in limited PCB spaces.

• Through-Hole Solder Termination
  Designed for through-hole PCB installation, offering a secure soldered connection between the connector and circuit board.

• 4 mm Contact Pitch
  A 4 mm centerline provides a defined spacing between contacts and supports a structured PCB connection layout.

Applications

1. Automotive Electronic Control Units (ECUs)
   Suitable for PCB-based control modules that require multiple power and signal connections between the circuit board and vehicle wiring harness.

2. Vehicle Electrical Systems
   The connector can be used in vehicle electrical assemblies where a board-mounted, right-angle connection is required for organized harness routing.

3. Body Control Electronics
   Can be applied to vehicle body electronics and control modules that combine multiple signal and power circuits within one PCB connection interface.

4. Automotive Wiring Harness Systems
   The wire-to-board configuration provides a practical interface between vehicle wiring harnesses and PCB-mounted electronic modules.

5. Industrial Electronic Equipment
   The connector format can also be considered for industrial control equipment and electronic assemblies where a sealed, right-angle board connection is required.
