RET Cables
>
8 pin Female Contacts AISG RET Cable To 6 Pins Crimp Terminal

8 pin Female Contacts AISG RET Cable To 6 Pins Crimp Terminal

Brand Name: BEDE
Model Number: AISG-0135
MOQ: 150pcs
Price: negotiation
Packaging Details: 150pcs per carton, packing in PE bag each with mounting nut and protective cap
Payment Terms: T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
CE RoHS
Pins:
8pin
Wire Gauge:
22AWG
Waterproof:
IP68
Rated Current:
3A
Insulation Resistance:
5MΩ
Contact Resistance:
3Ω Max
Supply Ability:
6500pcs per day
Highlight:

8pin aisg ret cable

,

Female aisg ret cable

,

8pin ret control cable

Product Description

RET Cables AISG 8 Pin Female Contacts To 6 Pins Crimp Terminal



Structure

1. cable, length 80 and 105mm in stock and customization is available. the cable's out diameter is 6.8mm, 5 cores, jacket with shielding layer which made of aluminum-magnesium alloy, and the coverage rate is greater than 85%

2. Heat shrink tube, black color or customized

3. Sealant, made of epoxy resin, for waterproofing

4. O-ring, Rubber, used for waterproofing

5.Shell of AISG female connector, copper materials with nickel plated

6. Insulator of AISG female connector, PBT materials

7. Crimp terminal, customization as needed is welcome

8. Contact pins of crimp terminal, brass with silver pleted



8 pin Female Contacts AISG RET Cable To 6 Pins Crimp Terminal 0



Pin location

     Female pin layout is based on DIN EN 61076-2-106:2012-04 variant 08-a. The female pins 2, 4 and 8 are not in
use for AISG applications, but it must be ensured that fully loaded male connectors according DIN EN 61076-2-
106:2012-04 variant 08-a are pluggable.

8 pin Female Contacts AISG RET Cable To 6 Pins Crimp Terminal 1

PIns No 1 2 3 4 5 6 7 8
wire color Blue not connect white not connect brown  red black not connect



Size

    size of the female connetor according AISG C485 4.1.1.3  style A3

8 pin Female Contacts AISG RET Cable To 6 Pins Crimp Terminal 2
