OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial

OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial
OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial

Large Image :  OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial

Product Details:
Place of Origin: China
Brand Name: BEDE
Certification: RoHS
Model Number: OHS Series Connectors
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: negotiate
Delivery Time: 5~8weeks
Payment Terms: T/T,Western Union,D/P
Supply Ability: 1000pcs per day
Detailed Product Description
Pin Count: 7-Pin Shell Size: 12
Contact Material: Copper Alloy (Gold/Silver Plated) Contact Size: Φ1.0
Rated Voltage: 250V Max Current Per Contact: 3.1A
Contact Resistance: ≤5MΩ Termination: Solder
Insertion Cycles: 250 Operating Temperature: -60℃~+85℃
Highlight:

OHS-BC-1-7/12-B1-1-B Connectors

,

Ultra-Small Connectors

,

OHS-BC-1-7/12-P12-1-B Connectors

OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial

Description

The OHS Series ultra-small bayonet connectors are designed for compact electronic systems where reliable connections and space efficiency are essential. These ultra-small circular connectors are ideal for compact electronic devices, instrumentation, communication equipment, and other space-limited applications. It supports multi-key positioning for precise installation and reliable mating.

Specifications

Product Series OHS Series Bayonet Ultra-Small Circular Connector Coupling Method Bayonet Locking
Contact Arrangement 4 / 7 / 10 / 19 / 32 / 50 Contacts Contact Type Pin & Socket
Rated Voltage 250 V AC/DC250 Contact Resistance ≤5 mΩ
Operating Temperature -60°C ~ +85°C


Product features

  • Reliable Electrical Performance for AC and DC Circuits

    Designed for stable signal and power transmission, the OHS Series supports AC and DC circuit applications with consistent electrical performance. Gold or silver plated contacts provide excellent conductivity, with low contact resistance and reliable connection stability during long-term operation.

  • Secure Bayonet Locking Mechanism

    Quick mating and unmating design with multiple keying options for accurate alignment and safe connection.

  • Outdoor and Harsh Environment Electrical Connections

    For applications exposed to vibration, temperature changes, dust, or moisture, sealed OHS versions provide enhanced environmental protection. They are suitable for outdoor electronic systems and industrial equipment operating under challenging conditions.

  • Russian Standard Industrial Equipment Replacement Applications

    OHS Series connectors are designed as compatible alternatives for Russian standard ОНЦ-БС series connectors. They are suitable for industrial equipment upgrades, maintenance replacement projects, and electrical systems originally designed with Russian standard interfaces.

    Feature Benefit
    Ultra Small Size Saves installation space
    Multiple Pin Options Supports various circuit designs
    Bayonet Locking Fast connection and reliable locking
    High Contact Reliability Stable signal transmission
    Industrial Grade Design Suitable for demanding environments


Applications

  • Industrial Automation and Control Systems

  • Outdoor and Harsh Environment Applications

  • Communication and Radio Equipment

  • Russian Standard Equipment Replacement


Size and layout


The external dimensions are shown in the image below. Please refer to them and determine if they are suitable for your product.

OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial
OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial
OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial
OHS Series Ultra Small Bayonet Circular Connector 4/50 Pin Micro Connector For Industrial

Installation Tips

  1. Align the connector key position correctly.

  2. Insert the plug into the socket.

  3. Rotate the bayonet locking ring until fully secured.

  4. Check connection stability before operation.

Maintenance Recommendations

  1. Keep connector contacts clean.

  2. Avoid excessive bending of cables.

  3. Inspect locking mechanism regularly.


FAQ

  1. What contact configurations are available for the OHS Series connector?

    A:The OHS Series is available with multiple contact arrangements, including 4, 7, 10, 19, 32, and 50 contacts. Different configurations allow flexible solutions for signal transmission, control circuits, and compact electrical systems.

  2. How do you ensure the quality of connectors?

    A:We implement strict quality control throughout the manufacturing process. Each connector is inspected for appearance, contact performance, assembly accuracy, and mechanical reliability before shipment. Pre-production samples are also available for customer approval before mass production.

  3. Do you provide samples before bulk orders?

    A:Yes. Samples are available for testing and evaluation before bulk production. This allows customers to verify connector dimensions, mating performance, and electrical characteristics before placing larger orders.

  4. Why choose your connectors?

    A:We focus on providing reliable circular connector solutions with competitive pricing, stable production capability, and professional technical support. Our experience in industrial connectors enables us to provide both standard products and customized connection solutions for global customers.

Packaging and Delivery

  • Customized packing solutions available

  • Fast production lead time

  • Global shipping support

Ratings & Review

Overall Rating

5.0
Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings
5 stars
100%
4 stars
0%
3 stars
0%
2 stars
0%
1 stars
0%

All Reviews

E
Ethan
Australia Apr 24.2026
Excellent service and product was received on time and as i Expected. very helpful
